Engine Vibration and Balancing Principles
What do you think when you’re flying home, cruising at 30,000 feet and the drinks have just been served? Our engineers think about the ripple in the glass. That ripple signals vibration and is an indication that the engine may be in need of a balance. The MTII’s PBS-4100+ Series Turbine Vibration Analyzer/Balancing System was developed to ensure that Turbine engines run as efficiently as possible. Excessive vibration is detrimental for a host of reasons: energy intended for useful output is instead expended on the vibration vibration manifests as acoustic energy (noise), again wasting otherwise useful energy excessive [...]
Handheld Signal Source Generator Principles
The MTI 1510A Portable Signal Generator is a sophisticated two channel battery powered microprocessor controlled direct digital synthesizer. It can generate sine, square, saw tooth and triangle continuous signals on both channels as well as single pulse and odd pulses on the B channel to simulate tachometer output pulses. The main reason for two channels is to be able to create a phase shift in the A to B output signals as may be encountered in a piece of rotating equipment such as a jet engine. The A channel also has the ability to simulate precise DC signals or [...]
Non-Contact Measurement
Non-Contact Measurement When you need nanometer-level accuracy without ever touching the part, MTI’s non-contact displacement sensors deliver. Our portfolio is organized into four sensor families each optimized for a different range, resolution, and application. MTI Instruments specializes in non-contact displacement sensors designed for extreme precision. Whether your application demands nanometer displacement measurement for precision manufacturing or picometer displacement measurement for scientific research and semiconductor metrology, our sensors deliver industry-leading accuracy and repeatability. Capacitance Sensors Measurements 25μm to 12mm Min. Resolution 20pm View Products Fiber Optic Sensors Measurements 102μm to 7.6mm Min. [...]
PBS-4100+ Portable Vibration and Balancing System
PBS-4100+ Portable Vibration and Balancing System Portable balancing system for gas turbine jet engines and vibration analysis Request a Quote Download Brochure April ‘25 Press Release Portable vibration analysis and engine trim balance instruments and accessories for commercial and military aviation. Designed to swiftly pinpoint jet engine problems and eliminate avoidable engine removals. Rapid configuration and intuitive user interface make this balancing system straightforward and uncomplicated to use. Portable Balancing System Vibration analysis and jet engine trim balance instruments and accessories for commercial and [...]
MICROTRAK 3: 1D Laser Displacement Sensor
MICROTRAK 3: 1D Laser Displacement Sensor An essential measurement tool for process automation, quality control and tool automation control. Request Quote Download Brochure Compact laser triangulation sensor head for easy integration to machine control system High resolution, high speed laser displacement sensor (non-contact linear displacement sensor) utilizes the latest CMOS sensor technology that challenges even the most difficult measurement applications. The Microtrak™ 3 is an essential measurement tool for process automation, quality control and tool automation control, for applications such as, thickness measurement, dimensional displacement, part profiling, vibrations testing, build-up [...]
Fotonic Plug-in Module
Fotonic Plug-in Module For measurement of dynamic edge position, displacement, and vibration at frequencies up to 500 kHz Request a Quote Sensitive Fiber Optic Measurement Sensors for nanomotion and vibration Measure dynamic edge position, displacement, and vibration at frequencies up to 500 kHz. The unique fiber optic probe design can accommodate a wide range of target reflectivity or shape, making it ideal for wide variety of applications such as ultrasonic horn vibration or Piezo electric materials studies. Random Fiber Distribution- As the probe-to-target distance increases, increasing amounts of light [...]
Fiber Optic MTI 2100 Fotonic Sensor
Fiber Optic MTI 2100 Fotonic Sensor Undoubtedly an essential measurement tool for process automation, quality control and tool automation control. REQUEST A QUOTE Download MTI-2100 Fotonic Sensor Brochure Download Fotonic Edge Probe Brochure Fast speed measurement sensor for ultrasonic horn vibration measurement The MTI-2100 features advanced fiber-optic non-contact sensor using reflectance electronic technologies for precise measurements of displacement, active vibration control, position, and distance for dynamic measurement in cryogenic, vacuum | high pressure, or in high magnetic field and harsh environment. It sets new performance standards with resolution up [...]
Manual Semiconductor Metrology System
Manual Semiconductor Metrology System Cost-effective alternative to full-automated wafer measurement and inspection systems Request a Quote Download Brochure Product can provide measurement of thickness and bow of all wafer materials including Silicon, Gallium-Arsenide, Indium-Phosphide and sapphire or tape. The Proforma 300i wafer thickness gauge is a capacitance based, differential measurement system that performs non-contact thickness measurements of semiconducting and semi-insulating wafers. By utilizing MTI Push/Pull technology, the Proforma 300i does not require the wafers to have a consistent electrical ground resulting in exceptional accuracy and repeatability for most [...]
Accumeasure AS-500 Modular Capacitance Rack System
Accumeasure AS-500 Modular Capacitance Rack System Multi-channel capacitance system designed for displacement, position and gap measurement Request Quote Download Data Sheet Accumeasure Probes Brochure Push/Pull Probes Brochure Compact by design, the Accumeasure TM 500 capacitve sensing sensor is ideal for in vehicle testing of brake rotors, axle runout, or thermal expansion testing using the DC model. Multiple racks may be synchronized together for multichannel operation on a common surface to avoid inter-channel interference. The Accumeasure TM 500 compact multi channel capacitance rack system accepts up to 6 capacitance [...]
Accumeasure OEM Boards
Accumeasure OEM Boards Custom High Accuracy OEM solutions for micro-positioning and feedback control applications Request Quote Data Sheet The Accumeasure MicroCap is a compact, custom designed, OEM capacitance board for high-precision non-contact displacement, thickness and gap measurement. The AccumeasureTM Microcap capacitance board allows rapid deployment for OEMs that require custom measurement solutions for micro-positioning, thermal correction, focusing and closed loop control applications. About Accumeasure OEM Boards The Accumeasure MicroCap is a compact, custom designed, OEM capacitance board for high-precision non-contact displacement, thickness and gap measurement. The AccumeasureTM Microcap capacitance board allows [...]
