Vitrek is a world leader in providing safety and electrical test equipment, solar & metrology systems, vibration/engine balancing systems, high-speed data acquisition and real-time RF recording & playback solutions to a range of industries including electronic, appliance and automotive manufacturers, calibration & test labs, R & D departments, medical, aerospace, military and lighting. Offering both the best equipment and top-notch support, choose Vitrek for your next test, measurement and high-speed data acquisition equipment needs.
Latest News!
Test & Measurement | Solar/Metrology | Engine Vibration & Balancing Systems
Since 1990, Vitrek has provided innovative global solutions for high voltage test and measurement. Vitrek brands include:
Vitrek: Test & Measurement Products including electrical safety compliance testers, multi-point high voltage switching systems, graphical power analyzers, electronic DC loads, compliance test management software.
MTI Instruments: precision tools, systems and solutions include turbine engine/rotating machine measurement & balancing systems, non-contact measurement solutions, semiconductor/solar metrology systems and portable signal/generators and calibrators.
XiTRON: portable calibrators for thermocouple and millivolt DC calibration, ballast testers, LED illumination spectral analyzers, programmable DC electronic loads, phase-angle voltmeters and digital milliohmmeters.
Vitrek also supplies precision high voltage measurement standards to national laboratories and calibration labs around the world.
This unique, and complementary, combination of product and engineering capabilities positions Vitrek as a leading provider of test solutions serving a variety of industries including electrical and appliance manufacturing, photovoltaic, medical equipment, power conversion, military, aerospace, industrial manufacturing/production and research, design and process development markets.
Data Acquisition and
RF Recording & Playback
Vitrek’s High-Speed Data Acquisition & RF Recording and Playback Division is the customer oriented industry leader in high-performance, accurate, and reliable data acquisition solutions. We serve a wide range of industries with card oriented instruments for test & measurement systems that are built on PCI Express, PXI Express, Thunderbolt, and other platforms.
Vitrek’s Data Acquisition & RF Recording & Playback brands include GaGe, Signatec, and KineticSystems. State of the art products range from high-speed standards-based instruments to ultimate performance custom source/acquisition systems. Each brand continues to innovate and invest in new products with outstanding features, better performance, and incredible value.
Our core competencies include engineering, manufacturing and integration of digitizers, signal conditioners, arbitrary waveform generators, downconverters and upconverters into continuous RF/IF signal analysis, recording, processing and generation systems.
Vitrek serves an impressive list of global entities, including direct government agencies, research institutes, universities, aerospace and defense contractors, large industrial corporations, and small technology-based businesses for applications that include Wideband Signal Analysis, RADAR Design & Test, Signals Intelligence (SIGINT), Ultrasonic Non-Destructive Testing (NDT), LIDAR Systems, Communications ,Optical Coherence Tomography (OCT), Mass Spectroscopy, Ultrasound Imaging, Time of Flight (TOF), Life Sciences, Particle Physics, And More….
Test & Measurement
Data Acquisition
95X Series Electrical Safety
Hipot Testers
Demanding applications call for the high power, high resolution 95X Series Hipot & Ground Bond Testers. With up to 200mA of Hipot source current – the 95X has plenty of power. Choose from up to 6, 10 or 30KVAC and up to 6.5, 11 or 15KVDC. Ground Bond models source up to 40 Amps and all models offer Tera-ohm class IR and a variety of interfaces.
V7X Series Electrical Safety
Hipot Testers
The Compact & Economical V7X Series Electrical Safety Testers with Easy-to-Use color touch screen set the standard for price/performance ratio. Choose from six V7X electrical safety tester models offering AC/DC Hipot to 5KV, IR to 450 Gig ohms, Ground Bond up to 30 amps, Continuity and Built-in HV Switching. USB, RS232, Digital I/O and HV Scanner control port all come standard.
GaGe eXpert FPGA
Signal Processing
GaGe provides several eXpert FPGA processing firmware options for use with CompuScope Digitizers. All standard default CompuScope Digitizer model configurations can store raw acquired waveform data to onboard sample memory and then transfer them quickly to the user for analysis, display and/or storage. The addition of optional eXpert FPGA processing firmware features allow for some signal processing analysis, or other specific functionality, to be performed on the digitizer hardware itself within its onboard Field Programmable Gate Array (FPGA).
Power
Analyzers
Introducing the Vitrek family of PA9xx Precision Harmonic Power Analyzers, refreshingly easy-to-use high performance power analyzers that won’t break your budget. With a variety of options to choose from, Vitrek’s power analyzers deliver multi-channel, high-accuracy, wideband performance – to tackle the toughest energy measurement applications.
High Voltage
Measurement
The Vitrek 4700 Precision High Voltage Meter offers the highest level of measurement accuracy, yet with its color touch screen – is surprisingly easy to use. The 4700 measures up to 10KV DC or rms AC directly and with available HV smartprobes, the measurement range can be extended to 35KV, 70KV, 100KV and 150KV.
GaGe GPU CUDA
Signal Processing
The PCI Express (PCIe) interface bus is the key pathway for transferring data to and from the GPU at very high-speeds. Taking advantage of the GaGe eXpert PCIe Data Streaming firmware capability, GaGe CompuScope PCIe Digitizer models can simultaneously acquire and stream data to the GPU at sustained rates up to 5 GB/s via a PCIe Gen3 interface.
High Voltage
Switching
The Vitrek 964i is the perfect solution for automated test systems including Multi-Conductor, Multi-Point Hipot Testing. Manual Hipot Testing on multi-point devices is error prone, labor intensive and operator hazardous. The 964i on the other hand, is purpose built to fully automate all of your HV switching needs. Let Vitrek build a 964i to satisfy your HV test system automation requirements.
Insulation Resistance
(IR) Testing
In a never ending race for higher efficiency, electric vehicles and solar panel arrays are now operating with voltage rails up to 2.5 KV. This is no place for a 1 KV tester, it’ time to step up to a Vitrek 98x!
Built upon the same DSP technology that has established Vitrek as a leader in hipot test systems, the 98xi devices feature a unique combination of performance features including Multi-dwell Functionality, High-speed Testing, Pico-Amp Leakage Measurement, Continuously Variable IR Test Voltage, Multi-mode IR and Capacitance Test Modes.
GaGe PC Oscilloscope
Software & SDKs
GaGe provides a powerful and easy-to-use PC oscilloscope software application, GaGeScope, for use with CompuScope digitizers without the need for any programming as well as a complete library of software development kits (SDKs) for C/C#, LabVIEW, and MATLAB for custom software application development.
Signatec Ultra-Portable
RF Signal Recorders
These Real-Time Spectrum Analyzer solutions feature ultra-portable configurations for real-time, long term recording of RF signals. Wideband signals up to 27 GHz can be viewed, analyzed, and recorded using system based packages that weigh less than 5.4 kg / 12 lb. to 10.8 kg / 24 lb. They can easily be transported on commercial airlines as carry-on luggage.
Electronic
DC Load
Vitrek’s DL Series Electronic Loads are available in a multiple configurations to meet your unique application requirements. No other electronic DC load on the market today is easier to use. Equipped with a full color LCD touchscreen display, the unit can quickly be set up for your next test. In addition, the DL is equipped with a comprehensive self-test that ensures that all loading and measurement circuitry is functioning properly.
Xitron
Products
XiTRON by Vitrek is Proud to Announce the Acquisition of XiTRON Technologies Brand & Product Lines
- Precision Power Analyzers
- Portable Power Quality Analyzer
- Portable Calibration Instrumentation
- Ballast Test Components & Systems
- Micro-Spectrometer
- Programmable DC Electronic Load
- Digital Millohmmeter
- Phase Angle Voltmeters
Signatec High-Speed Signal Recording Systems
Signatec has a long history of providing high-speed data recording and playback solutions. This expertise in delivering real-time systems saves customers time, and eliminates uncertainties when buying gap-free recording solutions. By providing turn-key hardware and software bundles, we provide customers with a very powerful and flexible signal recording system, while minimizing the risks of self-integrated systems.
Signatec systems are complete with integrated digitizers, data storage arrays, computer, and mouse driven continuous gap-free or pulsed data recording software. Customers can start recording analog signals when the system is received. All units are fully configured, and tested at maximum data rates before shipment.
Signatec Real-Time Digital Signal Processing
Signatec’s complete turnkey real-time digital signal processing systems featuring options for adding multiple digitizer channels for high-speed signal data recording and signal generation DAC playback. All systems come complete with GUI based software for performing all system settings, viewing digital data (either captured or generated), performing signal recordings and playbacks as well as the option for viewing data in either time domain or frequency domain.
Accumeasure Capacitance Sensors and Capacitance Displacement & Gap Measurement Probes
The Accumeasure product line features capacitive sensor products for high resolution gap and displacement measurements that require a high level of accuracy that is both stable and repeatable. A capacitive sensing system consists of a probe and amplifier. Capacitive measurements can be performed in a multitude of environments using non-contact passive capacitance probes that are not affected by magnet fields, temperature, humidity, nuclear radiation, and pressure. This is largely due to the nature of the rugged and passive capacitance probes.
Capacitance Displacement & Gap Measurement Probes
MTI offers probes for grounded targets using single-ended probes and for ungrounded or poorly grounded targets using push/pull probes.
1D Laser Systems
MTI Instruments offers high speed, high resolution and highly accurate 1D laser sensors (non-contact linear position sensor) for measuring displacement and position. Our laser measurement systems allow easy position setup and alignment with its visible laser position spot (check out laser safety standards before handling laser sensors). Quality and process control applications that require accurate warpage, alignment, lead position on integrated circuits, sheet and web thickness measurements can be precise and repeatable as our 1D laser displacement measurement sensors are equipped with an auto gain feature making it unaffected by surface (i.e. energy reflections) texture, color or stray light. Our large line up of non-contact displacement sensors including laser triangulation sensors provide operating distances to 300mm, measurement ranges to 200mm and measurement resolution to less than 1 micron.
Signatec High Speed Signal Generation/Playback
Signatec’s GUI based signal generation playback software is used to control one or more Signatec signal generator boards, performing all system settings, viewing digital data (either captured or generated), and performing signal generation / playback. Software includes PC based Oscilloscope and Playback Scope Application, Drivers and Libraries.
Signatec High Speed Data Acquisition Software
Signatec’s PC-based oscilloscope and spectrum analyzer software allows for performing all system settings, viewing digital data (either captured or generated), performing signal recordings as well as the option for viewing data in either time domain or frequency domain.
2D/3D Laser Measurement
This high speed 2-dimensional laser profile sensors are ideal for quality control and production applications for dimensional measurements, thickness, profiling, metal bending, weld bead, weld seam following and used as laser gap measurement. When it comes to laser measurements such as metal or plastic welding, 3D material inspection, component alignment, tire depth, angle measurements and more, MTI laser scanner heads can be easily integrated with PLC through HMI in quality control environment.
Fiber Optic Fotonic Sensors
MTI Instruments offers large measurement range and standoff distance fiber-optic measurement sensors and probes that provide ultra-sensitive linear output response. Our modular (interchangeable) non-contact fiber optic sensors systems have dual channel that enables the user to make simultaneous measurements. Our fiber optic probes are designed to automatically compensate large changes in reflectivity making it possible to monitor dynamic reflectance of up to 100:1 making it ideal for measuring vibration of ultrasonic horns, modal analysis of disk drive suspension, displacement and timing of fuel injectors and lateral motion measurements.
KineticSystems Analog & Digital I/O
KineticSystems brand products provide Analog & Digital I/O product solutions to meet demanding data acquisition and control requirements based on CompactPCI, PXI, VXI, and CAMAC standards. KineticSystems is a proud member of the PXI Systems Alliance and the VXI Bus Consortium, and is a recognized leader in CAMAC IEEE STD 583 products.
KineticSystems Signal Conditioning
Vitrek is proud to announce our new full line product catalog! This new catalog features presale and technical information on our complete line of Electrical Safety & High Voltage Test Equipment. The catalog includes XiTRON branded products and includes success stories, application information as well as technical details of our products.
Semiconductor/Solar Metrology Systems
Manual | Semi-Automated | Photovoltaic/Solar
Manual Semiconductor Metrology System
The Proforma 300i wafer thickness gauge is a capacitance-based, differential measurement system that performs non-contact thickness measurements of semiconducting and semi-insulating wafers.
Semi-automated Metrology System
The Proforma 300iSA is a benchtop/desktop, semi-automated wafer measurement system for semi-conducting and semi-insulating materials delivering full wafer surface scanning for thickness, thickness variation, bow, warp, sori, site and global flatness.
Photovoltaic/Solar Metrology System
A high-speed, multi-channel thickness, TTV and bow measurement module for in-process monitoring of solar/photovoltaic wafers and other materials.
Portable Hand-held Signal Simulators/Calibrators
Having a Precision Portable Signal Simulator and Calibrator is a must-have for engineers and technicians working in a variety of fields – from routine troubleshooting and maintenance, to calibrating and tuning advanced equipment such as eddy current probes, strain gauge amplifiers, or charge amplifiers for jet turbine vibration analysis.
KineticSystems
Multiplexers
Vitrek’s KineticSystems brand provides multiplexer product solutions to meet demanding data acquisition and control requirements based on CompactPCI / PXI standards. Vitrek is a proud member of the PXI Systems Alliance.
KineticSystems
Frequency Counters
Vitrek’s KineticSystems brand provides frequency counter product solutions to meet demanding data acquisition and control requirements based on CompactPCI, PXI, VXI, and CAMAC standards. Vitrek is a proud member of the PXI Systems Alliance and the VXI Bus Consortium, and is a recognized leader in CAMAC IEEE STD 583 products.
Rotating Engine & Vibration Balancing Systems
Looking for balancing systems? Commercial aviation companies and the U.S. military rely on MTI Instruments’ vibration analysis and engine trim balance solutions to identify any jet engine problems quickly, saving the time and cost of engine repair and maintenance.
The PBS eXpress is a vibration measurement and engine rotor balancing system that’s designed especially for the small-frame turbofan and turboprop engines that are used extensively in the regional jet, business jet, and general aviation markets. Lightweight, easy-to-setup, and easy-to-use.
The 4th generation of the PBS-4100+ sets the standard in turbine engine vibration analysis and balancing. Using the latest technology, the 4th generation PBS-4100+ continues to build on the field proven 35-year legacy of the industry’s leading vibration analysis and balancing tool.
Calibration
& Repair
Vitrek is pleased to provide world class customer support – before, during and after the sale. Vitrek is A2LA accredited to ISO 17025. Our highly skilled factory service technicians take pride in getting the job done right and providing standard cal/repair turnaround times that are among the fastest in the compliance and safety test equipment industry.
KineticSystems Data Acquisition & Control Software
Vitrek’s KineticSystems brand supplies cPCI/PXI systems ranging from a few channels tethered to a computer to thousands of channels remotely distributed through Local Area Network (LAN) connections. Whether the cPCI/PXI instrumentation systems are fixed purpose for specific testing or require flexibility for handling multi-role data acquisition, KineticSystems brand provides the instrumentation software tools for expedient implementation.
